Sparki the Arduino robot is going places with Atmel’s Atmega32u4RC

Sparki is an easy to use Arduino-based robot that offers a fun introduction to programming, electronics and robotics. Although Sparki is simple enough for beginners, the ‘bot is packed with more than enough features to satisfy more experienced Makers.

The robot is powered by Atmel’s Atmega32u4RC paired with with a custom serial/HID hybrid Arduino bootloader. Additional key hardware specs include an NRF24L01+ data radio, 128×64 LCD, an ultrasonic distance sensor, accelerometer, 3x light-sensing phototransistors, 5x line-following and edge detection sensors, IR bounce for gripper, RGB LED, buzzer, IR transmitter/receiver/remote, TL serial port for expansion, a port for Bluetooth serial module, 2x geared stepper motors and a marker holder for drawing.

“Sparki is ArcBotics’ answer to robotics in education. After our first successful Kickstarter for Hexy the Hexapod, a low-cost open-source Arduino robot designed to be an intro to advanced robotics, we were approached by many who asked if we had anything for beginners. When we looked around, we saw that other educational robots were very expensive, difficult to use, lacked features, or had closed designs,” an ArcBotic rep explained on Kickstarter.

“However, we know that the interest in programming and robotics from people of all ages is enormous. So we thought, why not design an adorable new robot that lets people of all ages enjoy robotics, while offering them a wide range of [fun] possibilities?”

On the software side, ArcBotic has partnered with the folks at MiniBloq to bring drag-and-drop programming to Sparki, all while developing free tutorials and lesson plans.

Currently, Sparki can be used to teach a number of introductory robotic concepts, including edge avoidance, line following, maze solving, wall avoidance, room navigation, object retrieval and shape drawing. More advanced concepts include PID loops, pathfinding algorithms, signal filtering and heuristics.

Sparki has raised over $184,000 from close to 1,600 backers. Additional information about the ‘bot can be found on Sparki’s official Kickstarter page here.

Wireless smart watch launches on Kickstarter

Pebble may have caused a splash in the watch-tech space, but Secret Labs and the House of Horology are about to make an even bigger one, with the Agent smart-watch.

Kicking off on Kickstarter today, the campaign promises to bring together a “fusion of New York fashion and cutting edge technology.” But of course, it would say that, wouldn’t it?

So, cutting through the hype, what’s actually cool about it?

The first thing that stood out to me, was the wireless charging aspect. That’s a big differentiator that sets the Agent apart from the competition, because it means the watch doesn’t have a USB port on it, allowing it to be properly waterproof.

As someone who already wrecked my Nike Fuelband in the pool (what the hell is the difference between “water resistant” and “water proof” anyway?!) this is kind of a big deal! Also… wireless charging! Nikola Tesla would be glowing with pride! We keep saying we live in a wireless world, so it’s about time we had the products to back up the notion.

I also like the fact that it’s cell phone agnostic, so whether you have an iPhone, Android, or Windows Phone, you can still connect to the device via Bluetooth. Because who wants to be locked into a phone just because you have a neat watch? (I’m naming no names, you know who I’m talking about!)

Agent does all the usual things you’d expect from a smart watch; it notifies you when you receive a call, beeps at you if it realizes you’ve left your phone behind (can anyone say “attachment issues”?), allows you to add all kinds of apps, like the weather, or GPS features. And of course the watch comes in a plethora of colors, so you can be ever so subtly different (from every eighth person who owns it).

It’s the innards of the watch, however, that I think are particularly compelling. Mostly because it makes pretty excellent use of battery resources by using both an Atmel Cortex-M4 (ARM A4 processor) micro with a smaller helper micro. The faster Cortex processor runs powerful watch apps while the smaller micro takes care of housekeeping services. Power when you need it, power saving when you don’t. Which is the whole point of a “smart” watch.

The dual-bank flash also makes sure that firmware gets upgraded painlessly without ever leaving the watch in a “bricked” condition, and it also apparently boasts “redundant fail-safe recovery modes” and “independent hardware-based reset features” to ensure that misbehaving apps can’t turn the watch into a nice looking paperweight.

Because make no mistake, it is nice looking.

The display is probably the nicest feature, and to my mind is the crispest to date for a smart watch. It also doesn’t look quite as bulky as some other digital timepieces I’ve seen on Kickstarter.

Keeping with the low energy theme, the Agent watch also supports both classic and low energy Bluetooth and sports a rechargeable battery that can be eventually replaced.

Best of all, in my mind? It’s assembled right here in the great US of A, which the team claims will significantly speed time to market, reduce manufacturing risk and allow them to be super duper nitpicky about build standards. Not to mention it allows them to create jobs here in America, which is always a good thing. Dare I suggest… it’s about time!

If the Kickstarter goes according to plan, full production is slated to begin in December of this year. Sound good? Go on over to the project page and check out the specifics.

Building an Android pinball game controller with Arduino

Who doesn’t love an old-school game of pinball? Sure, most of us probably don’t have the space or cash to splash out on a genuine pinball arcade machine for the living room, so we have to make do with playing a virtual version of the game.

Credit: Pacific Pinball Museum

Now I admit, I miss the satisfying thwack of the flippers just as much as anyone else, but we pinball wizards can’t always be in a bar drinking a cold beer, listening to bad heavy metal and stale classic rock tracks.

That being said, I’d be the first one to say that playing pinball on a tablet or phone leaves something to be desired, because you don’t even get the feeling of physically connecting with the game like you would with a PC or console game controller.

Then again, you could always build your own game controller, just like the folks at FunWithDCCircuits who designed a sweet electronic mashup for their Android tablet. Components include a Bluetooth modem, arcade buttons, an NTE 74LS00 Quad2-input NAND gate, 10k 1/6W resistors and an Arduino Uno.

For the uninitiated, the Arduino Uno is a microcontroller board based on Atmel’s stalwart ATmega328. It boasts a total of 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz ceramic resonator, a USB connection, a power jack, an ICSP header and a reset button.

Credit: Funwithdc.com

On the software (code) side, the owner of the blog chose not to implement a polling mode driver, as it is too easy to miss events, and the code isn’t quite as clean.

“Instead, I wired the outputs from the SR latches to pins 2 and 3 on my Arduino Uno, which are the external interrupt pins. Any change (press or release) on these pins will trigger an interrupt, and the registered interrupt service routine (ISR) will be called. In the ISR, I simply add the event to a ring buffer, and increment a counter indicating there is work to do in non-interrupt context,” the owner of FunWithDCCircuits explained.

Credit: Funwithdc.com

“Then, inside the loop() function, I check this counter and, if it is non-zero, pull an event off of the ring for processing. In this way, we can ensure that events are processed in the order in which they were received. And given how little code executes in interrupt context, we can be fairly certain that we won’t miss events. One thing to be careful of, though, is disabling interrupts when checking any variable that will be accessed by the ISR.”

Interested? Head over to the source code for a closer look at the software side and the FunWithDCCircuits blog for additional hardware info.

1:1 interview with Michael Koster

Series 3 – Why IoT Matters?

---

By Tom Vu, Digital Manifesto and Michael Koster, Internet of Things Council Member

---

Three-part Interview Series (Part 3)

---

Tom Vu (TV):  Describe how Internet of Things matters? Why should anyone care? Should futurist, technologist, data hounds, product extraordinaires, executives, and  common consumer need to understand what’s to come?

Michael Koster (MK):

There are two main effects we see in the Internet of Things. First, things are connected to a service that manages them. We can now monitor things, predict when they break, know when they are being used or not, and in general begin to exploit things as managed resources.

The second, bigger effect comes from the Metcalfe effect, or simply the network effect, of connecting things together. Bob Metcalfe once stated that the value of a communications network is proportional to the square of the number of connected compatible communicating devices. Since then it’s used to refer to users, but maybe Bob was thinking way ahead. Notice the word compatible. In this context, it means to be able to meaningfully exchange data.

When we connect physical objects to the network, and connect them together in such a way as to manage them as a larger system, we can exploit the Metcalfe effect applied to the resources. We are converting capital assets into managed resources and then applying network management.

Because Internet of Things will be built as a physical graph, it’s socialization of everything, from simple everyday devices to industrial devices. Metcalfe states that 10X connections is 100 times the value.  Cisco is projecting that the Internet of Everything has the potential to grow global corporate profits by 21 percent in aggregate by 2022. I believe these represent a case for pure information on one end, and an average efficiency gain over all of industry on the other.

This has the potential to change things from a scarcity model, where the value is in restricting access to resources, thus driving up price, to a distribution centered model, where value is in the greater use of the resource.  Connecting things to the network is going to reverse the model, from a model of “excluding access” to “inclusion access”, a model where you push toward better experience for consumer/customer/co-business.

Crowdsourcing of things is an example, where models are inverted.  The power arrow is going in the opposite direction, a direction equalizing toward the benefit of the massive body consumers and people.  This in turn, helps shift the business model from a customer relationship managed by vendors, also called advertising, to vendor relationship managed by customers. This is called Vendor Relationship Management, or VRM, pioneered by Doc Searls. This reverses the power arrow to point from customer needs toward business capability to meet needs, and needs are met now that the vendor is listening.  A lot of this is not just IoT but also open source nature, and the big changes happening in people, where sharing being held more valuable than the exclusion of access.

Inverting the value model, breaking down artificially bloated value chains, creating a more efficient economy, I believe it important to create a layer of connectivity that will act as the necessary catalyst to the next Internet of Everything, Internet of Things, Industrial Internet.  Break down the scarcity-based models, exclusion of access, turn it around. Instead of excluding access and driving prices up for limited resources, we will yield higher more efficient utilization of resources.

Michael Koster describing Internet of Things and the Maker Movement and Open Source Importance of this Development with Booth attendees at Maker Faire 2013 in San Mateo

It matters on a Global Scale, by giving us better resource utilization. SMART Grid alone has resulted in up to 19.5% efficiency improvement, with an average of 3.8% improvement over all deployments already. We do not have enough energy storage or transmission capacity to deal with the major shift to solar energy sources now in progress worldwide. We are going to have to adapt, learn, monitor, manage, and control our usage in ways only possible with large scale sensing and control.

For the spirit of IoT, it’s not only in making peoples/consumers lives more convenient, solving their first world problems, but its more in the ability to manage resources together as a larger system, from the individual out to a global scale. Especially, this holds true with the effects of globalization, balancing, localization, connectivity, and ubiquity.  It’s for the people.  Social Media had it’s transformation across many things, Internet of Things will also have an efficiency and business transformation.

Companies like Atmel play an important role in creating the building blocks for embedded control and connectivity by means of progressing the ARM / AVR / Wireless / Touch portfolio of products, all of which are the necessary thinking and connecting glue of the Internet of Things. Internet of Things has a large appetite for ultra low power connectivity using wireless standards.  Wireless Sensor Networks are key technology for the IoT, so much that WSN was probably the number one issue in the early deployment. There are many competing standards: Zigbee, SA100.11, Bluetooth, Body Area Network, Wi-Fi Direct, NFC, Z-Wave, EnOcean, KNX, XRF, WiFi, RFID, RFM12B, IEEE 802.15.4 (supporting WPAN such as ZigBee, ISA100.11a, WirelessHART, IrDA, Wireless USB, Bluetooth, Z-wave, Body Area Network, and MiWi).

Michael Koster Exhibiting with Atmel Booth at Maker Faire 2013 San Mateo

Tom Vu (TV):  What would be the most important design decision that supersedes the eventual success of an open source Internet of Things compliance?

Michael Koster (MK):

The first most important decisions are to do open source design based on needs and use cases. I don’t think we can build an IoT if its not open source, or if it’s not connected to the real world use cases.

Just like the Internet, built on open source and open standards, the starting data models are important for building on and building out. HTML and http and URLs allowed many platforms to be built for the web and supersede each other over time, for example Server Pages, SOAP, Javascript, and AJAX. A browser can understand all of the current platforms because they are all based on common abstractions. We believe that the Semantic Web provides a solid basis of standard web technology on which to base the data models.

Tom Vu (TV):  Describe the importance of Internet of Things silos and other M2M standards currently at large in the development community? What are the differences?

Michael Koster (MK):

The IoT has started off fueled by crowdfunding, VC money and other sources that have to some extent built on a business model based on vertical integration. Vertical integration has a big advantage; you need to have a self-contained development to get things done quickly for proof of concept and demonstration.

Vertical integration is also a big driver of the current machine-to-machine, or M2M, communication market. This is the paradigm supporting the initial deployment of connecting things to services for management on an individual thing basis.

The downside of vertical integration is that it leads to silos, where the code developed for a system, the data collected, and even the user interfaces are all unique to the system and not reusable in other systems. Moreover, the vertical integration is often seen as a proprietary advantage and protected through patents and copyrights that are relatively weak because they apply to commonly known patterns and methods.

It’s not always this way, though. As an example, the Eclipse foundation is open source, allowing their M2M system to be used for vertical application development as well as integrated with IoT Toolkit data models and APIs to enable interoperability with other platforms.

The European Telecommunications Standardization Institute, or ETSI, also has an M2M gateway that is a combination of open source and paid license code. New features are enabled through Global Enablers or GEs that implement a particular function using an OSGi bundle consisting of Java code. The Smart Object API can be built into ETSI through a GE bundle, which will enable an ETSI M2M instance to inter-operate with other IoT Toolkit instances. This is the power of the approach we’re taking for interoperability, which is obtained by adding a Smart Object API layer to the system.

Tom Vu (TV):  Explain horizontal and service interoperability for Internet of Things, why is it so important?

Michael Koster (MK):

Connected things connect through WSN gateways and routers to Internet services that fulfill the application logic for the user. Today, for the most part, each vendor provides a cloud service for the devices they sell, e.g. Twine, Smart Things, or the Nest thermostat. There are also some cloud services that allow any connection, providing an API for anyone to connect, for the purpose of integrating multiple devices. But the dedicated devices mentioned earlier don’t work with the generic cloud services.

Many IoT services today are based on providing easy access to the devices and gateway, with open source client code and reference hardware designs, selling hardware on thin margins, and Kickstarter campaigns. There is typically a proprietary cloud service with a proprietary or ad-hoc API from the device or gateway to the service, and a structured API to the service offering “cooked” data.

These systems contain a highly visible open source component, but much of the functionality comes from the cloud service. If a user wishes to use the open source part of the system with another service, the APIs will need to be adapted on either the device/gateway end or service end, or both. It’s not exactly a lock-in, but there is a fairly steep barrier to user choice.

Internet of Things (IoT) in Silos

There is the beginning of an ecosystem here, where some devices are being built to use existing services, e.g. Good Night Lamp uses Cosm as their cloud service. Other services that allow open API connectivity include Thingworx and Digi Device Cloud. These services all use very similar RESTful APIs to JSON and XML objects, but have different underlying data models. As a result, sensors and gateways must be programmed for each service they need to interact with.

The current system also leaves users vulnerable to outages of a single provider. Even if there was a programmable cloud service that all could connect to that ran user applications, there would be a vulnerability to provider outages. Much better and more robust would be an ability to configure more than one service provider in parallel in an application graph, for a measure of robustness in the face of service outages. Even more, it should be possible to run user application code in IoT gateways, local user-owned servers, or user-managed personal cloud services. Today’s infrastructure and business models are at odds with this level of robustness for users.

In terms of business and business models, a lot of the connection and network infrastructure today was built on a “value chain” model. These are businesses that are built on a model of vertical integration. In these models, value is added by integrating services together to serve one function, hence vertical.  With the Internet of Things, traditional value chains are collapsing down and flattening. There is a bit of a disruption in the business model (services, etc), but also new opportunities emerge to create new Internet of Things services, which is good for business and consumers.

Companies will continue to build out vertical models to specialize in their services. IoT can potentially augment service models with the customer even further and offer creative possibilities of cost savings and experience and deploy more customer centric business fabrics, which will result in better service for consumers.

If companies build their vertically based infrastructure of applications integrating into the IoT Toolkit platform, the basic enablement for horizontal connections will already exist, making it easy to create horizontal, integrative applications based on automatic resource discovery and linkage.

Access to the knowledge can enhance the customer experience and ROI for businesses.  We are at the brink of the new era, where companies and products can arise from the information economy; only now motivation via implicit or explicit engagement is tied to things, assets, information, sensors, education, and augmentation; and everything is more intertwined and involved.

Tom Vu (TV):  Please assume the role of a futurist or even contemporary pragmatist. How does the landscape of Internet of Things fit into that picture for an individual?

Michael Koster (MK):

It goes back to the idea that your life is going to change in ways that we are no longer be driven by the scarcity pressures we experienced as hunter gatherers. IoT will trigger the overall shift from the resource accumulative, to the interaction driven and resource sharing-enjoying model due to the ubiquitous connectivity and the right kind of applications we can use to bring this experience to maturity.

We expect the Internet of Things to be where the interaction moves away from screens and becomes more like everyday life, only more convenient, comfortable, and easy to manage. We’re still looking for the valet, the system that simply helps us manage things to enable us to become more as people.

Tom Vu (TV):  Do you have any insights into how industries like Semi-Conductor can help share the responsibility of making Internet of Things for the People and by the People?

Michael Koster (MK):

Yes, of course, everyone has a part in the build up and build out of Internet of Things.  From business to academia, in the home and across the planet, the march to Internet of Things is inevitable.  Again and again, the familiar signs of disruption are being seen.  We see that happening today with the very first initial releases of connected products.  There is a movement in Makers, with substantial global activity. Which is quite harmonious to open source and open hardware.  This will be even wider spread once critical mass takes effect with products more and more becoming connected and smart via Internet.  The power of the sensor proliferation is akin to Twitter having 10 people registered and using their Social Fabric versus 100s of millions.  The more everyday devices and things are connected, the more the power of IoT will overwhelmingly surface.

It’s only how well we integrate and collaborate together across industry to propel this next phase of Internet to the next level.  Every potential disruptive technology has a turning point.  We are at that point and we are all part of this movement. In turn, the Internet of Things will make better products, a better user experience, and optimized efficiency across all resources. How we decide to apply this technology will make all the difference.

This very notion forces industries to be more aware, efficient, and productive. Sensors and connected devices will help supply chain, manufacturing, research, product roadmaps, experience, and ultimately drive an economy of growth. The enterprise begins to have a visibility, transparency to customers, people.   Ultimate, it’s a true nervous system, connected via an enterprise level to a personal consumer level.

SMART, AWARE, and SENSORY are new enhancements to business to include customer habits and patterns of use, threaded right into the production routine and product design. Internet of Things will help sculpt a more consumer oriented and customer centric world of products. Customers will have direct influence in the manufacturing of individual products and instances of products.  Companies can help by being part of the community, albeit in the field of electrical engineering, design, data, to software development on the cloud.  Internet of Things will have touch points between customers and business as much as the electrical power grids have influence across all business today.

The new ecosystem will have micro scale and agile manufacturing at a level of customization unimaginable today. It’s the next driver for brilliant machines, maybe artisan-machines that work for individuals but still live on the factory floor.

You can work with the developers and work toward expanding businesses that can embrace the development world.  Help build the $50 cell phone or connected devices that bridge fiscal and energy compliance for a better world.

Ride the long tail wave… and the inverted business models…  Make more accessibility to all products and be responsible in accessibility… From crowdfunding or crowdsourcing, like Kickstarter or Makers, someone is going to figure out how a sensor can do more, in a very impactful and human experience paradigm. The new innovations will come from everywhere; from the 14 year old in Uganda who takes apart her cellphone to repurpose it into a medical monitoring device, from the basements and garages of millions of makers and DIY’ers worldwide who have sure genius among them.

It is super important to get the very latest hardware out to the open community so that innovation can be leveraged, taken to new levels of creativity and crowdsource ideation for collaboration and massive cross-contribution. Accessibility, documentation, development, ecosystem for software support for the MCUs are all too important.  Atmel holds building blocks to many of these pieces, combined with their development tools and evaluation ecosystem (Atmel Studio 6, Atmel Spaces, Atmel Gallery) and involvement with Makers and Arduino.

Open Hardware / Open Source will come to be de-facto standards.  Bundle open source along with the open hardware to make it even more accessible and embed rapid guide start for newcomers. Right now a key piece is the Wireless Sensor Net. If there were a good open source WSN available and supported by manufacturers, it could enable a groundswell of connected devices.

Build open source and open hardware educational IoT developer’s kits for ages 8 and up, for high school and college, to hit all levels of involvement and expertise. Support community hackspaces and places (ie Noisebridge) where everyone can learn about the digital world and programming.

We are seeing the leveling out of the development happening in all parts of the world. Radical innovation is happening everywhere. Open Source is helping shape this curvature.  This is the broader whole tide that we are seeing. Pinocchio is one great innovation emerging from Makers and Open Source, then we have IoT hubs such as SmartThings, Thingworx, or Xively (formerly Cosm).  There is a lot of crowdfunding, ideation, blooming of disruptive products looking to change the scene of things to come….
Support open source and open collaboration in everything, to create a culture of sharing and innovation, a culture of synergy in building the Internet of Things together. Involve customers as participants and makers of their own experiences. Make sure everyone has access to the information and support they need to build, maintain, hack, and repurpose their devices over time to promote a healthy ecosystem.

This time innovation is going global. The ideation is happening everywhere. There are many global Silicon Valley type hubs, other metros in the world, as well as global accessibility to the same information. We see startup mentality blossoming across all geo-locations.  Again, Semi-Conductors is contributing, helping pave the back-plane for innovation & connectivity for the development layers on top.  Global village of innovation is coming of age… Now.



Also read Part 1 and Part 2 of the Interview Series.
